solar panel
Cathy Zhu
Contact person
Basic Information
| Place of Origin | Jiangsu China (Mainland) |
|---|---|
| Brand Name | WF |
| Model Number | WFM-70M |
| Size | 1197*535*35 |
| Number of Cells | 36(9*4) |
| Max. Power | 70W |
| Material | Monocrystalline Silicon |
Specifications Tolerance +/- 3% CellMonocrystalline silicon solar cells 125*125mm No. of cells36(9*4) Dimension of Modules (mm) 1197*535*35 Weight 8KG Packing Configuration 2 pcs per carton Pallet Quantity52pcs/pallet Loading728 pcs/40ft; 350pcs/20ft Limits Operating Temperature-40 +85 Storage Temperature -40 +85 Maximum system voltage 1000 VDC max. Temperature and Coefficients NOCT 48C +-2C Voltage temperature coefficient -0.34 Current temperature coefficient 0.09 Power temperature coefficient -0.37 Model WFM-70D Max-power voltage (Vmp)17.2V Max-power current (Imp)4.07A Open-circuit voltage (Voc)20.81V Short-Circuit Current (Isc)4.95A Max-power (Pm)70WSTC: Irrandiance 1000w/m2, Module temperature 25C, AM=1.5
-
