260w poly crystalline solar panels
original price: 3,10 USD
Cathy Zhu
Contact person
Basic Information
| Place of Origin | Jiangsu China (Mainland) |
|---|---|
| Size | 1954*990*50 |
| Number of Cells | 72pcs |
| Max. Power | 260w |
| Material | Polycrystalline Silicon |
Specifications Tolerance +/- 3% Cell Polycrystalline silicon solar cells 156*156mm No. of cells 72(12*6) Dimension of Modules (mm)1954*990*50 Weight 28KG Packing Configuration 2 pcs per carton Pallet Quantity 36pcs/pallet Loading 504 pcs/40ft; 252pcs/20ft Limits Operating Temperature -40 +85 Storage Temperature -40 +85 Maximum system voltage 1000 VDC max. Temperature and Coefficients NOCT 48C +-2C Voltage temperature coefficient -0.34 Current temperature coefficient 0.05 Power temperature coefficient -0.45Model WFM-260P Max-power voltage (Vmp) 34.7V Max-power current (Imp)7.49A Open-circuit voltage (Voc)43.37V Short-Circuit Current (Isc) 8.56A Max-power (Pm) 260W STC: Irrandiance 1000w/m2, Module temperature 25C, AM=1.5
Delivery terms and packaging
Port: shanghai,China
-
