| Place of Origin |
Jiangsu China (Mainland) |
| Brand Name |
WFGF |
| Size |
1581*1068*40 |
| Number of Cells |
72pcs |
| Max. Power |
210w |
| Material |
Monocrystalline Silicon |
Specifications Tolerance +/- 3% Cell Monocrystalline silicon solar cells 125*125mm No. of cells and connections 96(12*8) Dimension of Modules (mm) 1581*1068*40 Weight 25.05KG Limits Operating Temperature -40 +85 Storage Temperature -40 +85 Maximum system voltage 1000 VDC max. Hail impact: diameter of 28mm with impact speed of 86km/h Temperature and Coefficients NOCT 48C +-2C Voltage temperature coefficient(%k) -0.34 Current temperature coefficient(%k) 0.09 Power temperature coefficient(%k) -0.37 Characteristics: Model DJ-210D Max-power voltage Vmp(V) 46.3 Max-power current Imp(A) 4.54 Open-circuit voltage Voc(V) 56.02 Short-Circuit Current Isc(A) 5.28 Max-power Pm(W)210STC: Irrandiance 1000w/m2, Module temperature 25C, AM=1.5
